欧美晶振
- 产品型号：40178894
- 晶振频率：10.77938MHz
- 晶振尺寸：3.2*2.5*0.9mm
- 产品应用： 欧美进口晶振,格耶晶振,KX-7石英晶振,无源晶振,12.60255晶振,晶体谐振器,3225贴片晶振,SMD晶振,四脚封装晶振,频率10.77938MHz,负载8pF,频率容差10ppm,工作温度-20~70°C,高精度晶振,小体积晶振,无铅环保晶振,智能手机...
-
12.60255|10.77938MHz|8pF|格耶高精度晶体
12.60255|10.77938MHz|8pF|格耶高精度晶体,欧美进口晶振,格耶晶振,KX-7石英晶振,无源晶振,12.60255晶振,晶体谐振器,3225贴片晶振,SMD晶振,四脚封装晶振,频率10.77938MHz,负载8pF,频率容差10ppm,工作温度-20~70°C,高精度晶振,小体积晶振,无铅环保晶振,智能手机晶振,笔记本电脑晶振,无线网络晶振,通讯设备晶振.
12.60255|10.77938MHz|8pF|格耶高精度晶体规格表
| part no. | 12.60255 |
| model | KX-7 |
| frequency range | 10.77938MHz |
|
mode |
fundamental |
| operating temperature | -20~+70℃ |
| frequency tolerance at +25°C | 土10 ppm |
| temperature tolerance |
土10 ppm
|
| storage temperature range | -55°C~+125℃ |
| load capacitance CL | 8 pF |
| shunt capacitance C0 typ. | 3.0 pF |
| series resistance R1 (ESR) max. | 60 Ohm |
| aging at +25°℃ (first year) max. | ±2 ppm |
| drive level | 200 μW max. |
| contents of reel | 1000 pcs. |
.jpg)
12.60255|10.77938MHz|8pF|格耶高精度晶体尺寸图
.jpg)
