欧美晶振
- 产品型号：57598667
- 晶振频率：32.768KHz
- 晶振尺寸：7.0*1.5*1.4mm
- 产品应用： 欧美进口晶振,Geyer晶振,KX-327LT无源晶振,石英晶振,12.87138晶振,晶体谐振器,7015贴片晶振,高端晶体,四脚晶振,频率32.768KHz,负载12.5pF,频率容差5ppm,工作温度-40~85°C,高可靠性晶振,高品质晶振,低老化晶振,个人电...
-
12.87138|32.768KHz|12.5pF|格耶进口晶振
12.87138|32.768KHz|12.5pF|格耶进口晶振,欧美进口晶振,Geyer晶振,KX-327LT无源晶振,石英晶振,12.87138晶振,晶体谐振器,7015贴片晶振,高端晶体,四脚晶振,频率32.768KHz,负载12.5pF,频率容差5ppm,工作温度-40~85°C,高可靠性晶振,高品质晶振,低老化晶振,个人电脑外围设备晶振,储存卡U盘晶振,数字水表晶振,智能家居晶振.
12.87138|32.768KHz|12.5pF|格耶进口晶振规格表
| part no. | 12.87138 |
| model | KX-327LT |
| frequency | 32.768 kHz |
| operating temperature | -40~+85℃ |
| frequency tolerance(df/F) at +25°C ±3°C | 土5ppm |
| temperature tolerance (parabolic coefficient) |
( -0.033 ±10 % ) × 10-6 / ℃2
|
| turnover temperature | +25°C±5℃ |
| storage temperature range | -55°C~+125℃ |
| load capacitance CL | 12.5pF |
| shunt capacitance C0 typ. | 0.8 pF |
| series resistance R1 (ESR) max. | 65 KOhm |
| aging at +25°℃ (first year) max. | ±3 ppm |
| drive level | 1 μW max. |
| contents of reel | 3000 pcs. |
.jpg)
12.87138|32.768KHz|12.5pF|格耶进口晶振尺寸图
