The ABS05 series is the perfect solution for time management in RTC circuits requiring small form factors. Our high-demand series of tuning fork crystals are low in power consumption preserving battery life in a wide range of applications.

ABS05比以前的ABS33节省空间多33%。ABS05器件在20ppm.25ppm的有效振荡器环路负载中提供±4PF的负载电容。4pF的低负载电容可节省功耗并缩短启动时间。

ABS05 allows for 33% more space-saving real estate than the previous ABS07. The ABS05 devices are available with ±20 ppm and ±25 ppm set-tolerance into an effective oscillator-loop load of 4.0pF. The low load-capacitance of 4pF saves power and allows for a faster start-up time.
Abracon旗下ABS05的优势及特点,ABS05-32.768KHZ-6-T晶振

特征

小型音叉晶体（1.60x1.00x0.50mm封装）

薄型-高度约束设计的理想选择

提供标准±20ppm设定公差

扩展温度范围-40°C至+85°C，适用于工业应用

应用:无线模块,物联网（IoT）,蓝牙/蓝牙低功耗,商业和工业应用,低功耗MCU、SoC、收发器,通信与测量设备

ABRACON编号	制造商	型号	频率	频率容差	负载电容
AB308-6.000MHZ	Abracon晶振	AB308	6 MHz	±30ppm	16pF
AB308-7.3728MHZ	Abracon晶振	AB308	7.3728 MHz	±30ppm	16pF
AB15T-32.768KHZ	Abracon晶振	AB15T	32.768 kHz	±20ppm	12.5pF
AB26TRB-32.768KHZ-T	Abracon晶振	AB26TRB	32.768 kHz	±20ppm	12.5pF
ABS07-32.768KHZ-T	Abracon晶振	ABS07	32.768 kHz	±20ppm	12.5pF
ABS07-32.768KHZ-7-T	Abracon晶振	ABS07	32.768 kHz	±20ppm	7pF
ABS07-166-32.768KHZ-T	Abracon晶振	ABS07	32.768 kHz	±10ppm	7pF
ABS07-32.768KHZ-9-T	Abracon晶振	ABS07	32.768 kHz	±20ppm	9pF
ABS07AIG-32.768KHZ-9-T	Abracon晶振	ABS07AIG	32.768 kHz	±20ppm	9pF
ABS07AIG-32.768KHZ-9-D-T	Abracon晶振	ABS07AIG	32.768 kHz	±20ppm	9pF
ABS07-32.768KHZ-9-4-T	Abracon晶振	ABS07	32.768 kHz	±30ppm	9pF
ABS07L-32.768KHZ-T	Abracon晶振	ABS07L	32.768 kHz	±20ppm	12.5pF
ABS07-32.768KHZ-1-T	Abracon晶振	ABS07	32.768 kHz	±10ppm	12.5pF
ABS05-32.768KHZ-T	Abracon晶振	ABS05	32.768 kHz	±20ppm	12.5pF
ABS05-32.768KHZ-9-T	Abracon晶振	ABS05	32.768 kHz	±20ppm	9pF
ABS06-32.768KHZ-T	Abracon晶振	ABS06	32.768 kHz	±20ppm	12.5pF
ABS06-32.768KHZ-9-T	Abracon晶振	ABS06	32.768 kHz	±20ppm	9pF
ABS06-32.768KHZ-1-T	Abracon晶振	ABS06	32.768 kHz	±10ppm	12.5pF
ABS05-32.768KHZ-7-T	Abracon晶振	ABS05	32.768 kHz	±20ppm	7pF
ABS05-32.768KHZ-X-T5	Abracon晶振	ABS05	32.768 kHz	±20ppm	4pF
ABS05-32.768KHZ-6-T	Abracon晶振	ABS05	32.768 kHz	±20ppm	6pF
ABS05-32.768KHZ-X-3-T3	Abracon晶振	ABS05	32.768 kHz	±25ppm	4pF
ABS06-32.768KHZ-9-1-T	Abracon晶振	ABS06	32.768 kHz	±10ppm	9pF
ABS05W-32.768KHZ-K-2-T	Abracon晶振	ABS05W	32.768 kHz	±20ppm	4pF
ABS07-32.768KHZ-4-T	Abracon晶振	ABS07	32.768 kHz	±30ppm	4pF
ABS07-32.768KHZ-9-H-T	Abracon晶振	ABS07	32.768 kHz	±20ppm	9pF
ABS07AIG-32.768KHZ-7-D-T	Abracon晶振	ABS07AIG	32.768 kHz	±20ppm	7pF
ABS05W-32.768KHZ-J-2-T	Abracon晶振	ABS05W	32.768 kHz	±20ppm	4pF
ABS06-32.768KHZ-7-T	Abracon晶振	ABS06	32.768 kHz	±20ppm	7pF
ABS04W-32.768KHZ-6-J2-T5	Abracon晶振	ABS04W	32.768 kHz	±20ppm	6pF
ABS04W-32.768KHZ-4-D2-T5	Abracon晶振	ABS04W	32.768 kHz	±20ppm	4pF
ABS04W-32.768KHZ-4-J2-T5	Abracon晶振	ABS04W	32.768 kHz	±20ppm	4pF
AB308-16.000MHZ	Abracon晶振	AB308	16 MHz	±30ppm	16pF
AB308-12.000MHZ	Abracon晶振	AB308	12 MHz	±30ppm	16pF
AB308-20.000MHZ	Abracon晶振	AB308	20 MHz	±30ppm	16pF
AB308-10.000MHZ	Abracon晶振	AB308	10 MHz	±30ppm	16pF
AB308-5.000MHZ	Abracon晶振	AB308	5 MHz	±30ppm	16pF
AB26T-32.768KHZ-E	Abracon晶振	AB26T	32.768 kHz	±20ppm	12.5pF
AB26T-32.768KHZ	Abracon晶振	AB26T	32.768 kHz	±20ppm	12.5pF
AB308-4.000MHZ	Abracon晶振	AB308	4 MHz	±30ppm	16pF
AB308-8.000MHZ	Abracon晶振	AB308	8 MHz	±30ppm	16pF
AB26TRQ-32.768KHZ-T	Abracon晶振	AB26TRQ	32.768 kHz	±20ppm	12.5pF
