Cardinal晶振CX252系列SMD晶体2520mm晶振
来源:http://taiheth.com 作者:泰河盛电子 2022年08月15
Cardinal为所有类型的应用提供全面的晶体组件。从标准微处理器到定制晶体,Cardinal工程师和销售人员致力于提供最好的技术支持和服务。
CX252系列SMD晶体,超薄厚度0.55mm,编码CX252Z-A0-B3C3-150-16.0D12,小体积尺寸2.5x2.0mm,四脚贴片晶振,石英晶体谐振器,这是一个完全密封的类型,金属外壳密封在陶瓷板上,自动安装是可能的。回流是可能的符合RoHs标准且无铅,
Cardinal晶振CX252系列SMD晶体2520mm晶振,CX252Z-A0-B3C3-150-16.0D12,石英晶体谐振器
Cardinal晶振CX252系列SMD晶体2520mm晶振,CX252Z-A0-B3C3-150-16.0D12,石英晶体谐振器
参数:
频率范围:12.0 ~ 54.0MHz无源晶振
Cardinal晶振CX252系列SMD晶体2520mm晶振,CX252Z-A0-B3C3-150-16.0D12,石英晶体谐振器
Manufacturer Part Number 原厂编码 | Manufacturer厂家 | Description 参数 | Series型号 |
CX5Z-A5B2C5-70-7.37280D18 | Cardinal Crystal | CRYSTAL 7.3728MHZ 18PF SMD | CX5 |
CX5Z-A5B2C5-70-7.37280D18 | Cardinal Crystal | CRYSTAL 7.3728MHZ 18PF SMD | CX5 |
CX5Z-A5B2C5-70-7.37280D18 | Cardinal Crystal | CRYSTAL 7.3728MHZ 18PF SMD | CX5 |
CX532Z-A2B3C5-70-12.288D18 | Cardinal Crystal | CRYSTAL 12.2880MHZ 18PF SMD | CX532 |
CX532Z-A2B3C5-70-12.288D18 | Cardinal Crystal | CRYSTAL 12.2880MHZ 18PF SMD | CX532 |
CX532Z-A2B3C5-70-12.288D18 | Cardinal Crystal | CRYSTAL 12.2880MHZ 18PF SMD | CX532 |
CX532Z-A2B3C5-70-16.0D18 | Cardinal Crystal | CRYSTAL 16.0000MHZ 18PF SMD | CX532 |
CX532Z-A2B3C5-70-16.0D18 | Cardinal Crystal | CRYSTAL 16.0000MHZ 18PF SMD | CX532 |
CX532Z-A2B3C5-70-16.0D18 | Cardinal Crystal | CRYSTAL 16.0000MHZ 18PF SMD | CX532 |
CX5Z-ARB2C5-70-7.3728D18 | Cardinal Crystal | CRYSTAL 7.3728MHZ 18PF SMD | CX5 |
CX5Z-ARB2C5-70-7.3728D18 | Cardinal Crystal | CRYSTAL 7.3728MHZ 18PF SMD | CX5 |
CX5Z-ARB2C5-70-7.3728D18 | Cardinal Crystal | CRYSTAL 7.3728MHZ 18PF SMD | CX5 |
CX325Z-A5B2C5-50-20.0D18 | Cardinal Crystal | CRYSTAL 20.0000MHZ 18PF SMD | CX325 |
CX325Z-A5B2C5-50-20.0D18 | Cardinal Crystal | CRYSTAL 20.0000MHZ 18PF SMD | CX325 |
CX325Z-A5B2C5-50-20.0D18 | Cardinal Crystal | CRYSTAL 20.0000MHZ 18PF SMD | CX325 |
CX635A-A5B2C3-40-18.432D13 | Cardinal Crystal | CRYSTAL 18.4320MHZ 13PF SMD | CX635A |
CX635A-A5B2C3-40-18.432D13 | Cardinal Crystal | CRYSTAL 18.4320MHZ 13PF SMD | CX635A |
CX635A-A5B2C3-40-18.432D13 | Cardinal Crystal | CRYSTAL 18.4320MHZ 13PF SMD | CX635A |
CX532Z-A2B3C5-70-12.0D18 | Cardinal Crystal | CRYSTAL 12.0000MHZ 18PF SMD | CX532 |
CX532Z-A2B3C5-70-12.0D18 | Cardinal Crystal | CRYSTAL 12.0000MHZ 18PF SMD | CX532 |
CX532Z-A2B3C5-70-12.0D18 | Cardinal Crystal | CRYSTAL 12.0000MHZ 18PF SMD | CX532 |
CX5Z-A5B2C5-40-27.0D18 | Cardinal Crystal | CRYSTAL 27.0000MHZ 18PF SMD | CX5 |
CX5Z-A5B2C5-40-27.0D18 | Cardinal Crystal | CRYSTAL 27.0000MHZ 18PF SMD | CX5 |
CX5Z-A5B2C5-40-27.0D18 | Cardinal Crystal | CRYSTAL 27.0000MHZ 18PF SMD | CX5 |
CX5Z-A5B2C5-40-24.0D18 | Cardinal Crystal | CRYSTAL 24.0000MHZ 18PF SMD | CX5 |
CX5Z-A5B2C5-40-24.0D18 | Cardinal Crystal | CRYSTAL 24.0000MHZ 18PF SMD | CX5 |
CX5Z-A5B2C5-40-24.0D18 | Cardinal Crystal | CRYSTAL 24.0000MHZ 18PF SMD | CX5 |
CX5Z-A5B2C5-40-24.576D18 | Cardinal Crystal | CRYSTAL 24.5760MHZ 18PF SMD | CX5 |
CX5Z-A5B2C5-40-24.576D18 | Cardinal Crystal | CRYSTAL 24.5760MHZ 18PF SMD | CX5 |
CX5Z-A5B2C5-40-24.576D18 | Cardinal Crystal | CRYSTAL 24.5760MHZ 18PF SMD | CX5 |
CX5Z-A5B2C5-70-8.0D18 | Cardinal Crystal | CRYSTAL 8.0000MHZ 18PF SMD | CX5 |
CX5Z-A5B2C5-70-8.0D18 | Cardinal Crystal | CRYSTAL 8.0000MHZ 18PF SMD | CX5 |
CX5Z-A5B2C5-70-8.0D18 | Cardinal Crystal | CRYSTAL 8.0000MHZ 18PF SMD | CX5 |
CX5Z-A1B2C5-40-24.0D18 | Cardinal Crystal | CRYSTAL 24.0000MHZ 18PF SMD | CX5 |
CX5Z-A1B2C5-40-24.0D18 | Cardinal Crystal | CRYSTAL 24.0000MHZ 18PF SMD | CX5 |
参数:
频率范围:12.0 ~ 54.0MHz无源晶振
振动模式:切割时,基本
频率容差:(25°C时):-/+ 10ppm,-/+ 30 ppm,或指定
频率稳定性:-/+ 10 ppm,-/+ 30 ppm,或指定
工作温度范围:-10~+60°C,或指定
分流电容:最大3.5pF。
负载电容:9pF、12pF或指定值
老化:-/+2 ppm/年,-/+5 ppm/年
驱动级别:最大100uW。
