FOXcrystal恒温晶振产品特性
来源:http://www.taiheth.com 作者:泰河电子晶振 2018年06月07
FOXcrystal恒温晶振产品特性
2014年2月18日,美国福克斯晶振公司携手全球领先变频控制解决方案供应商IDT晶振公司共同合作开发出低功耗,低电压,低电平,低抖动FTP302AH晶振,一款表面式贴片OCXO恒温晶振.其尺寸仅为14.3毫米*9.3毫米*6.7毫米,功耗仅为0.6W(最大值).新款贴片式OCXO低功率HCMOS振荡器可在宽温范围内提供超高的稳定特性.
新型SMD HCMOS OCXO集成了Stratum 3时钟,可提高时序性能。当其时序属性与紧凑尺寸相结合时,低功耗振荡器可用于越来越多的需要更小,更密集,但可靠性更高的电子设备的应用中。其中包括通信,数据传输和测试测量行业中的路由器,网关,基站和交换平台。
在5MHz至40MHz的频率范围内以及-40°C至+ 85°C的扩展工作温度下,FTP301AH的稳定性低至±50 ppb。采用业界标准尺寸,可用简单的磁带和卷轴配置,新型OCXO可轻松并入自动化生产线,以节省设计成本和装配时间。
OCXO晶振在前30天每天最多提供最大值±5 ppb的短期老化,对所有影响提供±4 ppm的长期提前老化。内部加热器和较小的封装有助于快速预热时间,以确保石英晶体振荡器快速达到就绪模式并具有准确的稳定性。
技术规格:
•典型频率稳定度:±100 ppb,可提供±50 ppb
•频率范围:5 MHz至40 MHz
•标准电源电压:3.3 V,5.0 V可用
•典型输出负载:15 pF,可用SineWave
•快速预热时间至±100 ppb:5分钟
•最大工作功率:25°C时为0.6 W.
•重量:5.4克
FOXcrystal constant temperature crystal product features
Stability of the FTP301AH is as low as ±50 ppb over a frequency range of 5 MHz to 40MHz and an extended operating temperature of -40°C to +85°C. Using an industry standard footprint and available in a simple tape and reel configuration, the new OCXO is easily incorporated into automated production lines to save design costs and assembly time.
The OCXO provides a short term aging of only ±5 ppb maximum per day for the first 30 days and ±4 ppm long term for all effects. The internal heater and smaller packaging facilitates a quick warm up time to ensure the oscillator quickly achieves ready mode with accurate stabilities.
Technical Specifications:
• Typical frequency stability: ±100 ppb, with ±50 ppb available
• Frequency range: 5 MHz to 40 MHz
• Standard supply voltage: 3.3 V, with 5.0 V available
• Typical output load: 15 pF, with SineWave available
• Fast warm up time to ±100 ppb: 5 minutes
• Maximum operating power: 0.6 W at 25°C
• Weight: 5.4 g
FOX CRYSTAL福克斯晶振相关资料阅读
FOX晶振公司简介
福克斯晶振FA5系列振荡器性能
FOXcrystal超小型石英晶体谐振器具有紧凑封装的显着性能
FOXcrystal恒温晶振产品特性
2014年2月18日,美国福克斯晶振公司携手全球领先变频控制解决方案供应商IDT晶振公司共同合作开发出低功耗,低电压,低电平,低抖动FTP302AH晶振,一款表面式贴片OCXO恒温晶振.其尺寸仅为14.3毫米*9.3毫米*6.7毫米,功耗仅为0.6W(最大值).新款贴片式OCXO低功率HCMOS振荡器可在宽温范围内提供超高的稳定特性.
新型SMD HCMOS OCXO集成了Stratum 3时钟,可提高时序性能。当其时序属性与紧凑尺寸相结合时,低功耗振荡器可用于越来越多的需要更小,更密集,但可靠性更高的电子设备的应用中。其中包括通信,数据传输和测试测量行业中的路由器,网关,基站和交换平台。
在5MHz至40MHz的频率范围内以及-40°C至+ 85°C的扩展工作温度下,FTP301AH的稳定性低至±50 ppb。采用业界标准尺寸,可用简单的磁带和卷轴配置,新型OCXO可轻松并入自动化生产线,以节省设计成本和装配时间。
OCXO晶振在前30天每天最多提供最大值±5 ppb的短期老化,对所有影响提供±4 ppm的长期提前老化。内部加热器和较小的封装有助于快速预热时间,以确保石英晶体振荡器快速达到就绪模式并具有准确的稳定性。
技术规格:
•典型频率稳定度:±100 ppb,可提供±50 ppb
•频率范围:5 MHz至40 MHz
•标准电源电压:3.3 V,5.0 V可用
•典型输出负载:15 pF,可用SineWave
•快速预热时间至±100 ppb:5分钟
•最大工作功率:25°C时为0.6 W.
•重量:5.4克
FOXcrystal constant temperature crystal product features
On February 18th, 2014, the United States Fox Crystal Corporation and IDT Crystal Corporation, a leading global supplier of variable frequency control solutions, jointly developed a low-power, low-voltage, low-level, low-pull FTP 302AH crystal oscillator, a surface-mount chip OCXO. Constant temperature crystal. Its size is only 14.3 mm * 9.3 mm * 6.7 mm, power consumption is only 0.6W (maximum). The new chip OCXO low power HCMOS oscillator can provide high stability over a wide temperature range.
The new SMD HCMOS OCXO incorporates a Stratum 3 clock for enhanced timing performance. When its timing attributes are coupled with its compact size, the low power oscillator can be used in a growing number of applications that require smaller,more dense, yet highly reliable, electronics. These include routers, gateways, base stations and switching platforms as found in the communications, data transmission and test and measurement industries.Stability of the FTP301AH is as low as ±50 ppb over a frequency range of 5 MHz to 40MHz and an extended operating temperature of -40°C to +85°C. Using an industry standard footprint and available in a simple tape and reel configuration, the new OCXO is easily incorporated into automated production lines to save design costs and assembly time.
The OCXO provides a short term aging of only ±5 ppb maximum per day for the first 30 days and ±4 ppm long term for all effects. The internal heater and smaller packaging facilitates a quick warm up time to ensure the oscillator quickly achieves ready mode with accurate stabilities.
Technical Specifications:
• Typical frequency stability: ±100 ppb, with ±50 ppb available
• Frequency range: 5 MHz to 40 MHz
• Standard supply voltage: 3.3 V, with 5.0 V available
• Typical output load: 15 pF, with SineWave available
• Fast warm up time to ±100 ppb: 5 minutes
• Maximum operating power: 0.6 W at 25°C
• Weight: 5.4 g
FOX CRYSTAL福克斯晶振相关资料阅读
FOX晶振公司简介
福克斯晶振FA5系列振荡器性能
FOXcrystal超小型石英晶体谐振器具有紧凑封装的显着性能
FOXcrystal恒温晶振产品特性
