康纳温菲尔德推出符合Stratum3E标准的14脚OCXO用于6G设备晶振,OH4610LF-020.000M晶振
来源:http://www.taiheth.com 作者:泰河盛电子 2023年07月12
康纳温菲尔德推出符合Stratum3E标准的14脚OCXO用于6G设备晶振,OH4610LF-020.000M晶振,伊利诺伊州奥罗拉,ConnorWinfield晶振公司新推出的OH414针DIP系列OCXO是基于SC切割晶体的振荡器专门设计用于与<1mH至.1Hz的低滤波器带宽配合使用,以符合基于T1的层次结构规范,例如ITU-TG.8262选项1和2ECC、ITU-TG.8263、ITU-TG.813选项1和2SEC,用于Sonet、IEEE1588和同步以太网的第3层和3E层。CW的OH4OCXO系列采用小尺寸14x20mm作为SMD或14引脚DIP通孔封装。
OH4OCXO晶振系列配置选项提供10ppb峰峰值频率稳定性、-40至+85C的工业温度范围以及出色的性能,低相位噪声、短期稳定性和老化特性。
康纳温菲尔德推出符合Stratum3E标准的14脚OCXO用于6G设备晶振,OH4610LF-020.000M晶振
特征:
•可用频率范围从10MHz到100MHz,标准频率为12.8MHz,19.2MHz、19.44MHz、20MHz、24.576MHz、25MHz、38.88MHz、40MHz和100MHz。
•3.3VLVCMOS或正弦输出
•固定输出或电压控制
•符合在.1Hz带宽下测量的层级MTIE和TDEV掩模
•10ppb峰峰值温度稳定性
•在12kHz-20MHz频段内低于300ps的抖动性能
•使用寿命精度为+/-1ppm
•完全符合ROHS和REACH标准
•14x20mm贴片或通孔封装选项 泰河电子
原厂代码 | 品牌 | 型号 | 类型 | 频率 | 输出 | 电压 | 频率稳定度 | 工作温度 |
DGOF5S3-020.0M | Connor-Winfield | DGOF | OCXO | 20MHz | HCMOS, TTL | 5V | 250ppb | 0°C ~ 70°C |
DGOF5S3-010.0M | Connor-Winfield | DGOF | OCXO | 10MHz | HCMOS, TTL | 5V | 250ppb | 0°C ~ 70°C |
DOCSC022F-025.0M | Connor-Winfield | DOCSC | OCXO | 25MHz | LVCMOS | 3.3V | ±20ppb | -40°C ~ 85°C |
DOCSC022F-025.0M | Connor-Winfield | DOCSC | OCXO | 25MHz | LVCMOS | 3.3V | ±20ppb | -40°C ~ 85°C |
DOCSC022F-025.0M | Connor-Winfield | DOCSC | OCXO | 25MHz | LVCMOS | 3.3V | ±20ppb | -40°C ~ 85°C |
OH4610LF-040.0M | Connor-Winfield | OH4 | OCXO | 40MHz | LVCMOS | 3.3V | ±10ppb | -40°C ~ 85°C |
OH4610LF-025.0M | Connor-Winfield | OH4 | OCXO | 25MHz | LVCMOS | 3.3V | ±10ppb | -40°C ~ 85°C |
OH100-61003CF-010.0M | Connor-Winfield | OH100 | OCXO | 10MHz | CMOS | 3.3V | ±10ppb | -40°C ~ 85°C |
OH300-61003CF-010.0M | Connor-Winfield | OH300 | OCXO | 10MHz | CMOS | 3.3V | ±10ppb | -40°C ~ 85°C |
OH300-61003CF-010.0M | Connor-Winfield | OH300 | OCXO | 10MHz | CMOS | 3.3V | ±10ppb | -40°C ~ 85°C |
OH300-61003CF-010.0M | Connor-Winfield | OH300 | OCXO | 10MHz | CMOS | 3.3V | ±10ppb | -40°C ~ 85°C |
BSOF3S3E-010.0M | Connor-Winfield | BSOF3S3E | OCXO | 10MHz | HCMOS | 3.3V | ±10ppb | 0°C ~ 70°C |
ASOF3S3-020.0M | Connor-Winfield | ASOF3S3 | OCXO | 20MHz | LVCMOS | 3.3V | 250ppb | 0°C ~ 70°C |
ASOF3S3-012.8M | Connor-Winfield | ASOF3S3 | OCXO | 12.8MHz | LVCMOS | 3.3V | 250ppb | 0°C ~ 70°C |
OH100-50503CF-010.0M | Connor-Winfield | OH100 | OCXO | 10MHz | CMOS | 3.3V | ±5ppb | 0°C ~ 70°C |
OH100-50503CF-012.8M | Connor-Winfield | OH100 | OCXO | 12.8MHz | CMOS | 3.3V | ±5ppb | 0°C ~ 70°C |
OH100-61003CF-020.0M | Connor-Winfield | OH100 | OCXO | 20MHz | CMOS | 3.3V | ±10ppb | -40°C ~ 85°C |
ASOF3S3-010.0M | Connor-Winfield | ASOF3S3 | OCXO | 10MHz | LVCMOS | 3.3V | 250ppb | 0°C ~ 70°C |
OH100-61003CF-012.8M | Connor-Winfield | OH100 | OCXO | 12.8MHz | CMOS | 3.3V | ±10ppb | -40°C ~ 85°C |
OX400-620LF-020.0M | Connor-Winfield | OX400-620LF | OCXO | 20MHz | LVCMOS | 3.3V | ±20ppb | -40°C ~ 85°C |
OX400-620LF-024.576M | Connor-Winfield | OX400-620LF | OCXO | 24.576MHz | LVCMOS | 3.3V | ±20ppb | -40°C ~ 85°C |
OH4610LF-38.88M | Connor-Winfield | OH4 | OCXO | 38.88MHz | LVCMOS | 3.3V | ±10ppb | -40°C ~ 85°C |
OH100-70503CF-024.576M | Connor-Winfield | OH100 | OCXO | 24.576MHz | CMOS | 3.3V | ±5ppb | -20°C ~ 70°C |
OH100-70503CF-020.0M | Connor-Winfield | OH100 | OCXO | 20MHz | CMOS | 3.3V | ±5ppb | -20°C ~ 70°C |
OH300-70503CF-020.0M | Connor-Winfield | OH300 | OCXO | 20MHz | CMOS | 3.3V | ±5ppb | -20°C ~ 70°C |
OH300-70503CF-020.0M | Connor-Winfield | OH300 | OCXO | 20MHz | CMOS | 3.3V | ±5ppb | -20°C ~ 70°C |
OH300-70503CF-020.0M | Connor-Winfield | OH300 | OCXO | 20MHz | CMOS | 3.3V | ±5ppb | -20°C ~ 70°C |
OHSM100-60803CF-010.0M | Connor-Winfield | OHSM100-60803CF | OCXO | 10MHz | LVCMOS | 3.3V | ±8ppm | -40°C ~ 85°C |
OH200-61003CF-024.576M | Connor-Winfield | OH200 | OCXO | 24.576MHz | CMOS | 3.3V | ±5ppb | -40°C ~ 85°C |
OH100-60503CF-024.576M | Connor-Winfield | OH100 | OCXO | 24.576MHz | CMOS | 3.3V | ±5ppb | -40°C ~ 85°C |
OH200-61003CF-020.0M | Connor-Winfield | OH200 | OCXO | 20MHz | CMOS | 3.3V | ±5ppb | -40°C ~ 85°C |
DOCSC022F-024.576M | Connor-Winfield | DOCSC | OCXO | 24.576MHz | LVCMOS | 3.3V | ±20ppb | -40°C ~ 85°C |
DOCSC022F-024.576M | Connor-Winfield | DOCSC | OCXO | 24.576MHz | LVCMOS | 3.3V | ±20ppb | -40°C ~ 85°C |
DOCSC022F-024.576M | Connor-Winfield | DOCSC | OCXO | 24.576MHz | LVCMOS | 3.3V | ±20ppb | -40°C ~ 85°C |
OH200-51003CF-012.8M | Connor-Winfield | OH200 | OCXO | 12.8MHz | CMOS | 3.3V | ±5ppb | 0°C ~ 70°C |
OH200-51003CF-005.0M | Connor-Winfield | OH200 | OCXO | 5MHz | CMOS | 3.3V | ±5ppb | 0°C ~ 70°C |
OH100-50503CF-020.0M | Connor-Winfield | OH100 | OCXO | 20MHz | CMOS | 3.3V | ±5ppb | 0°C ~ 70°C |
OH300-61003CF-012.8M | Connor-Winfield | OH300 | OCXO | 12.8MHz | CMOS | 3.3V | ±10ppb | -40°C ~ 85°C |
OH300-61003CF-012.8M | Connor-Winfield | OH300 | OCXO | 12.8MHz | CMOS | 3.3V | ±10ppb | -40°C ~ 85°C |
OH300-61003CF-012.8M | Connor-Winfield | OH300 | OCXO | 12.8MHz | CMOS | 3.3V | ±10ppb | -40°C ~ 85°C |
OH300-50503CF-020.0M | Connor-Winfield | OH300 | OCXO | 20MHz | CMOS | 3.3V | ±5ppb | 0°C ~ 70°C |
OH300-50503CF-020.0M | Connor-Winfield | OH300 | OCXO | 20MHz | CMOS | 3.3V | ±5ppb | 0°C ~ 70°C |
OH300-50503CF-020.0M | Connor-Winfield | OH300 | OCXO | 20MHz | CMOS | 3.3V | ±5ppb | 0°C ~ 70°C |
OH300-70503CF-024.576M | Connor-Winfield | OH300 | OCXO | 24.576MHz | CMOS | 3.3V | ±5ppb | -20°C ~ 70°C |
OH300-70503CF-024.576M | Connor-Winfield | OH300 | OCXO | 24.576MHz | CMOS | 3.3V | ±5ppb | -20°C ~ 70°C |
OH300-70503CF-024.576M | Connor-Winfield | OH300 | OCXO | 24.576MHz | CMOS | 3.3V | ±5ppb | -20°C ~ 70°C |
OH300-50503CF-012.8M | Connor-Winfield | OH300 | OCXO | 12.8MHz | CMOS | 3.3V | ±5ppb | 0°C ~ 70°C |
OH300-50503CF-012.8M | Connor-Winfield | OH300 | OCXO | 12.8MHz | CMOS | 3.3V | ±5ppb | 0°C ~ 70°C |
OH300-50503CF-012.8M | Connor-Winfield | OH300 | OCXO | 12.8MHz | CMOS | 3.3V | ±5ppb | 0°C ~ 70°C |
OH300-60503CF-024.576M | Connor-Winfield | OH300 | OCXO | 24.576MHz | CMOS | 3.3V | ±5ppb | -40°C ~ 85°C |
OH300-60503CF-024.576M | Connor-Winfield | OH300 | OCXO | 24.576MHz | CMOS | 3.3V | ±5ppb | -40°C ~ 85°C |
OH300-60503CF-024.576M | Connor-Winfield | OH300 | OCXO | 24.576MHz | CMOS | 3.3V | ±5ppb | -40°C ~ 85°C |
OH300-61003CF-020.0M | Connor-Winfield | OH300 | OCXO | 20MHz | CMOS | 3.3V | ±10ppb | -40°C ~ 85°C |
OH300-61003CF-020.0M | Connor-Winfield | OH300 | OCXO | 20MHz | CMOS | 3.3V | ±10ppb | -40°C ~ 85°C |
OH300-61003CF-020.0M | Connor-Winfield | OH300 | OCXO | 20MHz | CMOS | 3.3V | ±10ppb | -40°C ~ 85°C |
OH300-50503CF-010.0M | Connor-Winfield | OH300 | OCXO | 10MHz | CMOS | 3.3V | ±5ppb | 0°C ~ 70°C |
OH300-50503CF-010.0M | Connor-Winfield | OH300 | OCXO | 10MHz | CMOS | 3.3V | ±5ppb | 0°C ~ 70°C |
OH300-50503CF-010.0M | Connor-Winfield | OH300 | OCXO | 10MHz | CMOS | 3.3V | ±5ppb | 0°C ~ 70°C |
OH300-61003CF-040.0M | Connor-Winfield | OH300 | OCXO | 40MHz | CMOS | 3.3V | ±10ppb | -20°C ~ 70°C |
OH300-61003CF-040.0M | Connor-Winfield | OH300 | OCXO | 40MHz | CMOS | 3.3V | ±10ppb | -20°C ~ 70°C |
OH300-61003CF-040.0M | Connor-Winfield | OH300 | OCXO | 40MHz | CMOS | 3.3V | ±10ppb | -20°C ~ 70°C |
OHSM100-60803CF-020.0M | Connor-Winfield | OHSM100-60803CF | OCXO | 20MHz | LVCMOS | 3.3V | ±8ppm | -40°C ~ 85°C |
DOCSC022F-040.0M | Connor-Winfield | DOCSC | OCXO | 40MHz | LVCMOS | 3.3V | ±20ppb | -40°C ~ 85°C |
DOCSC022F-040.0M | Connor-Winfield | DOCSC | OCXO | 40MHz | LVCMOS | 3.3V | ±20ppb | -40°C ~ 85°C |
DOCSC022F-040.0M | Connor-Winfield | DOCSC | OCXO | 40MHz | LVCMOS | 3.3V | ±20ppb | -40°C ~ 85°C |
OH4610LF-024.576M | Connor-Winfield | OH4 | OCXO | 24.576MHz | LVCMOS | 3.3V | ±10ppb | -40°C ~ 85°C |
DOCSC022F-020.0M | Connor-Winfield | DOCSC | OCXO | 20MHz | LVCMOS | 3.3V | ±20ppb | -40°C ~ 85°C |
DOCSC022F-020.0M | Connor-Winfield | DOCSC | OCXO | 20MHz | LVCMOS | 3.3V | ±20ppb | -40°C ~ 85°C |
DOCSC022F-020.0M | Connor-Winfield | DOCSC | OCXO | 20MHz | LVCMOS | 3.3V | ±20ppb | -40°C ~ 85°C |
OH4610LF-012.8M | Connor-Winfield | OH4 | OCXO | 12.8MHz | LVCMOS | 3.3V | ±10ppb | -40°C ~ 85°C |
OH4610LF-010.0M | Connor-Winfield | OH4 | OCXO | 10MHz | LVCMOS | 3.3V | ±10ppb | -40°C ~ 85°C |
OH4610LF-020.0M | Connor-Winfield | OH4 | OCXO | 20MHz | LVCMOS | 3.3V | ±10ppb | -40°C ~ 85°C |
ASOF5S3-012.8M | Connor-Winfield | ASOF5S3 | OCXO | 12.8MHz | HCMOS | 5V | 250ppb | 0°C ~ 70°C |
ASOF5S3-019.44M | Connor-Winfield | ASOF5S3 | OCXO | 19.44MHz | HCMOS | 5V | 250ppb | 0°C ~ 70°C |
OH200-51003CF-010.0M | Connor-Winfield | OH200 | OCXO | 10MHz | CMOS | 3.3V | ±5ppb | 0°C ~ 70°C |
OFC5DJ3BS-010.0M | Connor-Winfield | OFC5DJ3BS | OCXO | 10MHz | Sine Wave | 5V | ±20ppb | -20°C ~ 70°C |
OFC5DJ3BS-020.0M | Connor-Winfield | OFC5DJ3BS | OCXO | 20MHz | Sine Wave | 5V | ±20ppb | -20°C ~ 70°C |
DOCSC012F-020.0M | Connor-Winfield | DOCSC | OCXO | 20MHz | LVCMOS | 3.3V | ±10ppb | -40°C ~ 85°C |
OH300-50503CF-025.0M | Connor-Winfield | OH300 | OCXO | 25MHz | CMOS | 3.3V | ±5ppb | 0°C ~ 70°C |
OH300-50503CF-025.0M | Connor-Winfield | OH300 | OCXO | 25MHz | CMOS | 3.3V | ±5ppb | 0°C ~ 70°C |
OH300-50503CF-025.0M | Connor-Winfield | OH300 | OCXO | 25MHz | CMOS | 3.3V | ±5ppb | 0°C ~ 70°C |
OH300-50503CF-040.0M | Connor-Winfield | OH300 | OCXO | 40MHz | CMOS | 3.3V | ±5ppb | 0°C ~ 70°C |
OH300-50503CF-040.0M | Connor-Winfield | OH300 | OCXO | 40MHz | CMOS | 3.3V | ±5ppb | 0°C ~ 70°C |
OH300-50503CF-040.0M | Connor-Winfield | OH300 | OCXO | 40MHz | CMOS | 3.3V | ±5ppb | 0°C ~ 70°C |
OH300-61003CF-025.0M | Connor-Winfield | OH300 | OCXO | 25MHz | CMOS | 3.3V | ±10ppb | -40°C ~ 85°C |
OH300-61003CF-025.0M | Connor-Winfield | OH300 | OCXO | 25MHz | CMOS | 3.3V | ±10ppb | -40°C ~ 85°C |
OH300-61003CF-025.0M | Connor-Winfield | OH300 | OCXO | 25MHz | CMOS | 3.3V | ±10ppb | -40°C ~ 85°C |
DOCSC012F-040.0M | Connor-Winfield | DOCSC | OCXO | 40MHz | LVCMOS | 3.3V | ±10ppb | -40°C ~ 85°C |
OH300-50503CF-050.0M | Connor-Winfield | OH300 | OCXO | 50MHz | CMOS | 3.3V | ±5ppb | 0°C ~ 70°C |
OH300-50503CF-050.0M | Connor-Winfield | OH300 | OCXO | 50MHz | CMOS | 3.3V | ±5ppb | 0°C ~ 70°C |
OH300-50503CF-050.0M | Connor-Winfield | OH300 | OCXO | 50MHz | CMOS | 3.3V | ±5ppb | 0°C ~ 70°C |
OH300-61003CF-050.0M | Connor-Winfield | OH300 | OCXO | 50MHz | CMOS | 3.3V | ±10ppb | -40°C ~ 85°C |
OH300-61003CF-050.0M | Connor-Winfield | OH300 | OCXO | 50MHz | CMOS | 3.3V | ±10ppb | -40°C ~ 85°C |
OH300-61003CF-050.0M | Connor-Winfield | OH300 | OCXO | 50MHz | CMOS | 3.3V | ±10ppb | -40°C ~ 85°C |
