TXC Automotive Crystals and Oscillators
来源:http://www.taiheth.com 作者:泰河盛电子 2023年08月16
Automotive Crystal and OscillatorTXC晶体
Key Differences | Automotive | Consumer/Industrial |
Identification | “A” product series Documents marked “ACAP” | Other than “A” product series |
Engineer/Operators | Automotive training program with qualification level, dedicated full time | TXC standard training program |
Production Line | Dedicated | Mix |
Reliability |
Automotive grade AEC-Q100 & AEC-Q200 + customer requirement |
Consumer grade + customer requirement |
New product design to manufacturing | Advance Product Quality Planning (APQP) | |
Specification | -40 to 105C, 125C and 150C | -40 to 85C, 105C or by customer specification |
Final test | 100% | Based on customer requirement |
Qualification process | PPAP, PSW (TXC PQSO) | TXC PQSO |
Record retention | 15 years | 5 years |
Quality Assurance system | ISO/TS16949, VDA6.3 | QS9001, ISO/TS16949 |
Type | Product Series | Frequency Range | Temperature Range | Manufacturing |
Crystal | AS (HC-49S) | 4~62.4MHz | -40~+105℃ | China |
AT (HC-49S/SMD) | 4~62.4MHz | -40~+105℃ | ||
AX (8045 Glass) | 6~40MHz | -40~+150℃ | ||
AA (5032 Glass) | 8~48MHz | -40~+150℃ | ||
AV (3225 Glass) | 9.84~62.4Mhz | -40~+125℃ | ||
AH (3215 Seam) | 32.768kHz | -40~+125℃ | ||
AB (5032 Seam) | 8~50MHz | -40~+125℃ | Taiwan | |
AM (3225 Seam) | 10~50MHz | -40~+125℃ | ||
AZ (2520 Seam) | 16~80MHz | -40~+125℃ | ||
AY (2016 Seam) | 16~50MHz | -40~+125℃ | ||
XO (CMOS) | AC (5032 Seam) | 1~70MHz | -40~+105℃ | Taiwan |
AU (3225 Seam) | 1~70MHz | -40~+125℃ | ||
AW (2520 Seam) | 4~54MHz | -40~+125℃ | ||
TCXO | AQ (3225Seam) | 13~52MHz | -40~+105℃ | |
AL(2520 Seam) | 13~52MHz | -40~+105℃ | ||
TSX | AE(2520 Seam) | 19.2MHz | -40~+105℃ |
AEC is an abbreviation of "Automotive Electronics Council." AEC is an industry organization that promotes the standardization of reliability or qualification standards for automotive electronic components, consisting of major auto manufacturers and major electronic component manufacturers in the USA. The AEC-Qxxx standards are widely adopted as standards for automotive electronic components, practically serving as the industry standards.These standards are classified into the following groups,according to the component category:
AEC-Q100: Integrated circuits (ICs)
AEC-Q200: Passive components (capacitors, inductors, etc.)石英晶振
PPAP – What is PPAP?
Production Part Approval Process (PPAP) is a standardized process in the automotive and aerospace industries that helps manufacturers and suppliers communicate and approve production designs and processes before, during, and after manufacture.
OTR – Why the need of wider Operating Temperature Range?
An operating temperature is the temperature at which an electrical or mechanical device operates. The device will operate effectively within a specified temperature range which varies based on the device function and application context, and ranges from the minimum operating temperature to the maximum operating temperature (or peak operating temperature). Outside this range of safe operating temperatures the device may fail. Automotive generally operate over a broader temperature range than industrial devices; commercial-grade devices generally have the narrowest operating temperature range.
Please refer to the Automotive grading chart.石英晶体振荡器
Automotive Record Retention – Why is longer time-frame?
Automotive Electronics suppliers are required to be certified under TS-16949 & ISO9001, under TS & ISO system there’s a standard requirement for record retention set by OEM car manufacturers.
Production – Why automotive has dedicated production line?
Automotive Timing device is put into dedicated production line due to the fact that the quality standard differs from consumer applications. Automotive tier one customers uses “Zero Defect” concept (0ppm) to audit its suppliers, as well as mandating its suppliers to implement the same concept into its subtiers. Production control processes are more stringent than the ones producing consumer products.
Zero Defects (or ZD) was a management-led program to eliminate defects in industrial production that enjoyed brief popularity in American industry from 1964[1] to the early 1970s. Quality expert Philip Crosby later incorporated it into his "Absolutes of Quality Management" and it enjoyed a renaissance in the American
TXC原厂编码 | 生产厂家 | 型号 | 频率 | 频率稳定度 | 频率偏差 | 负载电容 | 工作温度 |
9HT7-32.768KDZF-T | TXC晶振 | 9HT7 | 32.768kHz | - | ±20ppm | 12.5pF | -40°C ~ 85°C |
9HT7-32.768KDZF-T | TXC晶振 | 9HT7 | 32.768kHz | - | ±20ppm | 12.5pF | -40°C ~ 85°C |
9HT7-32.768KDZF-T | TXC晶振 | 9HT7 | 32.768kHz | - | ±20ppm | 12.5pF | -40°C ~ 85°C |
9HT10-32.768KBZF-T | TXC晶振 | 9HT10 | 32.768kHz | - | ±50ppm | 12.5pF | -40°C ~ 85°C |
9HT10-32.768KBZF-T | TXC晶振 | 9HT10 | 32.768kHz | - | ±50ppm | 12.5pF | -40°C ~ 85°C |
9HT10-32.768KBZF-T | TXC晶振 | 9HT10 | 32.768kHz | - | ±50ppm | 12.5pF | -40°C ~ 85°C |
9HT10-32.768KDZF-T | TXC晶振 | 9HT10 | 32.768kHz | - | ±20ppm | 12.5pF | -40°C ~ 85°C |
9HT10-32.768KDZF-T | TXC晶振 | 9HT10 | 32.768kHz | - | ±20ppm | 12.5pF | -40°C ~ 85°C |
9HT10-32.768KDZF-T | TXC晶振 | 9HT10 | 32.768kHz | - | ±20ppm | 12.5pF | -40°C ~ 85°C |
9HT10-32.768KEZF-T | TXC晶振 | 9HT10 | 32.768kHz | - | ±10ppm | 12.5pF | -40°C ~ 85°C |
9HT10-32.768KEZF-T | TXC晶振 | 9HT10 | 32.768kHz | - | ±10ppm | 12.5pF | -40°C ~ 85°C |
9HT10-32.768KEZF-T | TXC晶振 | 9HT10 | 32.768kHz | - | ±10ppm | 12.5pF | -40°C ~ 85°C |
7A-27.120MAAE-T | TXC晶振 | 7A | 27.12MHz | ±30ppm | ±30ppm | 12pF | -20°C ~ 70°C |
7A-27.120MAAE-T | TXC晶振 | 7A | 27.12MHz | ±30ppm | ±30ppm | 12pF | -20°C ~ 70°C |
7A-27.120MAAE-T | TXC晶振 | 7A | 27.12MHz | ±30ppm | ±30ppm | 12pF | -20°C ~ 70°C |
7A-24.000MAAJ-T | TXC晶振 | 7A | 24MHz | ±30ppm | ±30ppm | 18pF | -20°C ~ 70°C |
7A-24.000MAAJ-T | TXC晶振 | 7A | 24MHz | ±30ppm | ±30ppm | 18pF | -20°C ~ 70°C |
7A-24.000MAAJ-T | TXC晶振 | 7A | 24MHz | ±30ppm | ±30ppm | 18pF | -20°C ~ 70°C |
7A-16.000MAAJ-T | TXC晶振 | 7A | 16MHz | ±30ppm | ±30ppm | 18pF | -20°C ~ 70°C |
7A-16.000MAAJ-T | TXC晶振 | 7A | 16MHz | ±30ppm | ±30ppm | 18pF | -20°C ~ 70°C |
7A-16.000MAAJ-T | TXC晶振 | 7A | 16MHz | ±30ppm | ±30ppm | 18pF | -20°C ~ 70°C |
7A-8.000MAAJ-T | TXC晶振 | 7A | 8MHz | ±30ppm | ±30ppm | 18pF | -20°C ~ 70°C |
7A-8.000MAAJ-T | TXC晶振 | 7A | 8MHz | ±30ppm | ±30ppm | 18pF | -20°C ~ 70°C |
7A-8.000MAAJ-T | TXC晶振 | 7A | 8MHz | ±30ppm | ±30ppm | 18pF | -20°C ~ 70°C |
7A-12.000MAAJ-T | TXC晶振 | 7A | 12MHz | ±30ppm | ±30ppm | 18pF | -20°C ~ 70°C |
7A-12.000MAAJ-T | TXC晶振 | 7A | 12MHz | ±30ppm | ±30ppm | 18pF | -20°C ~ 70°C |
7A-12.000MAAJ-T | TXC晶振 | 7A | 12MHz | ±30ppm | ±30ppm | 18pF | -20°C ~ 70°C |
7A-25.000MAAJ-T | TXC晶振 | 7A | 25MHz | ±30ppm | ±30ppm | 18pF | -20°C ~ 70°C |
7A-25.000MAAJ-T | TXC晶振 | 7A | 25MHz | ±30ppm | ±30ppm | 18pF | -20°C ~ 70°C |
7A-25.000MAAJ-T | TXC晶振 | 7A | 25MHz | ±30ppm | ±30ppm | 18pF | -20°C ~ 70°C |
7A-27.120MAAJ-T | TXC晶振 | 7A | 27.12MHz | ±30ppm | ±30ppm | 18pF | -20°C ~ 70°C |
7A-27.120MAAJ-T | TXC晶振 | 7A | 27.12MHz | ±30ppm | ±30ppm | 18pF | -20°C ~ 70°C |
7A-27.120MAAJ-T | TXC晶振 | 7A | 27.12MHz | ±30ppm | ±30ppm | 18pF | -20°C ~ 70°C |
7A-24.000MAHE-T | TXC晶振 | 7A | 24MHz | ±30ppm | ±30ppm | 12pF | -40°C ~ 85°C |
7A-24.000MAHE-T | TXC晶振 | 7A | 24MHz | ±30ppm | ±30ppm | 12pF | -40°C ~ 85°C |
7A-24.000MAHE-T | TXC晶振 | 7A | 24MHz | ±30ppm | ±30ppm | 12pF | -40°C ~ 85°C |
7A-10.000MAAJ-T | TXC晶振 | 7A | 10MHz | ±30ppm | ±30ppm | 18pF | -20°C ~ 70°C |
7A-10.000MAAJ-T | TXC晶振 | 7A | 10MHz | ±30ppm | ±30ppm | 18pF | -20°C ~ 70°C |
7A-10.000MAAJ-T | TXC晶振 | 7A | 10MHz | ±30ppm | ±30ppm | 18pF | -20°C ~ 70°C |
8Z-27.120MAAV-T | TXC晶振 | 8Z | 27.12MHz | ±30ppm | ±30ppm | 8pF | -20°C ~ 70°C |
8Z-27.120MAAV-T | TXC晶振 | 8Z | 27.12MHz | ±30ppm | ±30ppm | 8pF | -20°C ~ 70°C |
8Z-27.120MAAV-T | TXC晶振 | 8Z | 27.12MHz | ±30ppm | ±30ppm | 8pF | -20°C ~ 70°C |
8Y-16.000MAAV-T | TXC晶振 | 8Y | 16MHz | ±30ppm | ±30ppm | 8pF | -20°C ~ 70°C |
8Y-16.000MAAV-T | TXC晶振 | 8Y | 16MHz | ±30ppm | ±30ppm | 8pF | -20°C ~ 70°C |
8Y-16.000MAAV-T | TXC晶振 | 8Y | 16MHz | ±30ppm | ±30ppm | 8pF | -20°C ~ 70°C |
7V-12.000MAAE-T | TXC晶振 | 7V | 12MHz | ±30ppm | ±30ppm | 12pF | -20°C ~ 70°C |
7V-12.000MAAE-T | TXC晶振 | 7V | 12MHz | ±30ppm | ±30ppm | 12pF | -20°C ~ 70°C |
7V-12.000MAAE-T | TXC晶振 | 7V | 12MHz | ±30ppm | ±30ppm | 12pF | -20°C ~ 70°C |
7V-24.000MAAE-T | TXC晶振 | 7V | 24MHz | ±30ppm | ±30ppm | 12pF | -20°C ~ 70°C |
7V-24.000MAAE-T | TXC晶振 | 7V | 24MHz | ±30ppm | ±30ppm | 12pF | -20°C ~ 70°C |
7V-24.000MAAE-T | TXC晶振 | 7V | 24MHz | ±30ppm | ±30ppm | 12pF | -20°C ~ 70°C |
7V-16.000MAAE-T | TXC晶振 | 7V | 16MHz | ±30ppm | ±30ppm | 12pF | -20°C ~ 70°C |
7V-16.000MAAE-T | TXC晶振 | 7V | 16MHz | ±30ppm | ±30ppm | 12pF | -20°C ~ 70°C |
7V-16.000MAAE-T | TXC晶振 | 7V | 16MHz | ±30ppm | ±30ppm | 12pF | -20°C ~ 70°C |
7V-25.000MAAE-T | TXC晶振 | 7V | 25MHz | ±30ppm | ±30ppm | 12pF | -20°C ~ 70°C |
7V-25.000MAAE-T | TXC晶振 | 7V | 25MHz | ±30ppm | ±30ppm | 12pF | -20°C ~ 70°C |
7V-25.000MAAE-T | TXC晶振 | 7V | 25MHz | ±30ppm | ±30ppm | 12pF | -20°C ~ 70°C |
7V-12.000MAHE-T | TXC晶振 | 7V | 12MHz | ±30ppm | ±30ppm | 12pF | -40°C ~ 85°C |
7V-12.000MAHE-T | TXC晶振 | 7V | 12MHz | ±30ppm | ±30ppm | 12pF | -40°C ~ 85°C |
7V-12.000MAHE-T | TXC晶振 | 7V | 12MHz | ±30ppm | ±30ppm | 12pF | -40°C ~ 85°C |
AA-8.000MALV-T | TXC晶振 | AA | 8MHz | ±150ppm | ±30ppm | 8pF | -40°C ~ 125°C |
AA-8.000MALV-T | TXC晶振 | AA | 8MHz | ±150ppm | ±30ppm | 8pF | -40°C ~ 125°C |
AA-8.000MALV-T | TXC晶振 | AA | 8MHz | ±150ppm | ±30ppm | 8pF | -40°C ~ 125°C |
7B-8.000MAAJ-T | TXC晶振 | 7B | 8MHz | ±30ppm | ±30ppm | 18pF | -20°C ~ 70°C |
7B-8.000MAAJ-T | TXC晶振 | 7B | 8MHz | ±30ppm | ±30ppm | 18pF | -20°C ~ 70°C |
7B-8.000MAAJ-T | TXC晶振 | 7B | 8MHz | ±30ppm | ±30ppm | 18pF | -20°C ~ 70°C |
7B-12.000MAAJ-T | TXC晶振 | 7B | 12MHz | ±30ppm | ±30ppm | 18pF | -20°C ~ 70°C |
7B-12.000MAAJ-T | TXC晶振 | 7B | 12MHz | ±30ppm | ±30ppm | 18pF | -20°C ~ 70°C |
7B-12.000MAAJ-T | TXC晶振 | 7B | 12MHz | ±30ppm | ±30ppm | 18pF | -20°C ~ 70°C |
7B-25.000MAAJ-T | TXC晶振 | 7B | 25MHz | ±30ppm | ±30ppm | 18pF | -20°C ~ 70°C |
7B-25.000MAAJ-T | TXC晶振 | 7B | 25MHz | ±30ppm | ±30ppm | 18pF | -20°C ~ 70°C |
7B-25.000MAAJ-T | TXC晶振 | 7B | 25MHz | ±30ppm | ±30ppm | 18pF | -20°C ~ 70°C |
7B-24.000MAAJ-T | TXC晶振 | 7B | 24MHz | ±30ppm | ±30ppm | 18pF | -20°C ~ 70°C |
